20 KVA Socoemc UPS on rent

Product Description

Socomec ITYS PRO 20 kVA UPS Specifications

Power Rating:

• Apparent Power: 20 kVA

• Active Power: 18 kW

• Power Factor: 0.9

Input:

• Phases: 3-phase + Neutral

• Voltage: 320 to 480 VAC (at 0.5 to 1.0 p.u. of nominal load)

• Frequency Range: 40 to 70 Hz

• Input Power Factor: >0.98

• Input Current THDi: <3%

Output:

• Voltage (Single-Phase): 1-phase: 220/230/240 VAC 1% (configurable)

• Voltage (Three-Phase): 3-phase: 380/400/415 VAC 1%

• Frequency: 50 or 60 Hz (0.1% with internal clock)

• Crest Factor: 3:1

• Voltage Distortion (THD):

  • <2% with linear load

  • <5% with non-linear load

• Overload Capacity:

  • 125% for 10 minutes

  • 150% for 1 minute

• Bypass: Rated output voltage 15% or 20% (with generator selectable)

Efficiency:

• Online Double Conversion Mode:

  • Without Transformer: Up to 95%

  • With Transformer: 91% to 93% depending on load

• ECO Mode: Up to 98%

Battery:

• Battery Options: Internal or External

• Compatible with Battery Cabinets

• Backup Time: Varies by battery cabinet and block configuration

• Configurable battery runtime from short to extended duration setups

UPS Cabinet & Build:

• Noise Level:

  • Without Transformer: <51 dBA

  • With Transformer: <54 dBA

• Cooling: Forced ventilation

• Degree of Protection: IP20

• Standards:

  • Safety: EN 62040-1

  • EMC: EN 62040-2

  • Performance: EN 62040-3

• Environmental:

  • Altitude: Up to 1000 m without derating

  • Operating Temp: 0 to 40C

Communication & Monitoring:

• Interfaces:

  • RS232 / RS485

  • SNMP / MODBUS (optional)

• Local View: LED + LCD Display

• Monitoring Software: VIEWPOWER, WEB BROWSER, NETVISION

• Dry Contacts: Optional via communication board
