30 KVA Socoemc UPS on rent

Product Description

Socomec MASTRYS BC 30 kVA UPS Specifications

Power Rating:

• Apparent Power (Sn): 30 kVA

• Active Power (Pn): 27 kW

• Power Factor: 0.9

Input:

• Configuration: 3/3 (3-phase input and output)

• Rated Voltage: 400 V 3Ph + N

• Voltage Tolerance: 20%

• Rated Frequency: 50/60 Hz

• Frequency Tolerance: 10%

• Total Harmonic Distortion (THDi): < 3%

Output:

• Rated Voltage:

  • 1Ph: N 230 V (can be configured 220/240 V)

  • 3Ph: N 400 V (can be configured 380/415 V)

• Voltage Tolerance: Static load 1%, dynamic load in accordance with VFI-SS-111

• Rated Frequency: 50/60 Hz

• Frequency Tolerance: 2% (configurable from 1% to 8%)

• Overload Capacity:

  • 125% for 10 minutes

  • 150% for 1 minute

• Crest Factor: 3:1

Bypass:

• Rated Voltage: Rated output voltage

• Voltage Tolerance: 15% (configurable from 10% to 20%)

• Rated Frequency: 50/60 Hz

• Frequency Tolerance: 2% (configurable for genset compatibility)

Efficiency:

• Online Mode @ 100% Load: Up to 94.5%

Environment:

• Operating Temp: 0C to +40C (*+15C to +25C for max battery life)

• Humidity: 95% without condensation

• Max Altitude: 1000 m (with de-rating, max 3000 m)

• Noise (at 1 m):

  • Cabinet Type S: 52 dBA

  • Cabinet Type M: 58 dBA

  • Cabinet Type T: 62 dBA

Cabinet & Physical:

• Dimensions (W x D x H): 444 x 795 x 1400 mm

• Weight (without batteries): 135 kg

• Protection Degree: IP20

• Color: RAL 7012

Standards:

• Safety: IEC/EN 62040-1-1, AS 62040.1.1

• EMC: IEC/EN 62040-2, AS 62040.2

• Performance: IEC/EN 62040-3, AS 62040.3

• Product Declaration: CE, RCM, EAC, UkrSEPRO
